Automatic Carton Box Folder Gluer Machine 1200x2400mm For Making Carton Boxes

Name: Automatic Carton Box Folder Gluer Machine 1200x2400mm For Making Carton Boxes
Brand: Toprint
Price: 1 USD

Automatic Carton Box Folder Gluer Machine 1200x2400mm For Making Carton Boxes Manufactures

Brand Name : Toprint

Model Number : 1200x2400mm

Certification : Patent Certificate, CE Certificate

Place of Origin : Foshan, Guangdong, China

MOQ : 1 Set

Price : Negotiation

Supply Ability : 3 Sets per Month

Delivery Time : 60-90 days

Packaging Details : Steel Base with Carton and Bopp Film Wrapping

Name : Flexo Folder Gluer, FFG, Carton Box Making Machine

Application : For All kind of Carton Boxes Making, Carton Industry

Service : Technican Video Support, Factory Arrangement, Online Support, Dispatch Engineer for Installation and Training

Automatic Type : Fully Automatic from Feeding to Finished Carton

Port of Loading : Guangzhou or Shenzhen Port

Voltage : 380V 50HZ or Custom

Condition : Brand NEW

Key Words : boxes folder and gluer, Inlline FFG, Inline Folder Gluer, Flexo Folder Gluer

High Light : Four Color Flexo Printer Slotter Inlline Folder Gluer

Contact Now

Flexo Inline Folder Gluer, Carton Box Gluing Machine, Automatic Folder Gluer Machine.

Main Features

Automatic Carton Box Folder Gluer Machine 1200x2400mm For Making Carton Boxes

The machine adopted independent Industrial Computer (with Keyboard) combined with PLC in each Unit of machine that could be adjust automatically by data inputting or order management system, easy to operate and change orders, greatly save time and labor cost, which can also connect with Corrugated Cardboard Production Line System, can greatly improve the production efficiency.
The whole machine is driving uniformly, pneumatic interlocking, each single unit OPEN/CLOSE with safety protection device.
Each Unit equipped with EMG. Switch can stop the unit moving inside of units, to ensure safety.
Design Speed 300sheets/min (0920), 250sheets/min (1224). Normal Working Speed can be from 150-280 sheets/min (0920), 120-250 sheets/min (1224), can easy reach to the production capacity of more than 100,000 cartons, greatly improve the production efficiency.
All main transmission gears use special imported materials, carburizing and quenching, precision grinding, durable and stable; gear lubrication using oil pump spray system.
All the Electronic Components adopt International famous brand, durable and stable, and main electric box equipped with Industrial Constant Air Conditioner, and all electric boxes equipped with Dust-proof, cooling device, to ensure stable running.
The machine is equipped with automatic Oil Balance Device & automatic Circle Lubrication System.
Printing Unit adopts Vacuum transfer, widely application for cardboard, especially when the machine is closed, Each Unit suction devices are connected together to ensure same pressure, which is more accurate printing and save adjusting time and cardboard.
Can easy to match with Pre-feeder and Automatic Strapping Machine, 2-4 staffs for whole operation.
Rubber & Anilox Roller quickly dis-assemble device.
The Whole machine Register Servo Control, more fasting for order change, and more accurate printing.
With automatic Ink Monitor System and Automatic Washing System.
Inline Folder Gluer with 9 Servo Motors Control, see bellow details.

Main Paramters

Automatic Carton Box Folder Gluer Machine 1200x2400mm For Making Carton Boxes

Model Parameters (MM)			1224
Max.Sheet Size (FxA)			1190x2400
Skip Feed Size (FxA)			1400x2400
Min.Sheet Size (FxA)			380x780
Max.Printing Area (FxA)			1190x2360
Top Speed (Sheet/min)			250
Economic Speed (sheet/min)			120-200
Max. Slot Depth Size			300
Min. Box Height Size (E)			110
Max. Die-Cutting Area (FxA)			1150x2350
(Max. size) (B+C)			≤1180 mm
(Min. size) (B+C)			≥380mm
(Max. size) (B)			1030mm
(Min. size) (B)			280mm
(Max. size) (C)			900mm
(Min. size) (C)			100mm
(Glue Flap Width) (D)			≤40mm
Sheet Thickness			1.5-11
Printing Plate Thickness (Sponge + Film + Plate)			7.2
Main Working Power (KW)		4 Colors Slotter Die-cutter + Inline Folder Gluer	70+40
Total Power(KW)		4 Colors Slotter Die-cutter + Inline Folder Gluer	100+51
Dimension (mm)		4 Colors Slotter Die-cutter	10500x5200x2630
		Inline Folder Gluer	14300x2600x2650
Frame Thickness	Flexo Printer		60mm
	Folder Gluer		40mm

Feeding Unit - Leade Edge Feeder

Printing Unit - Vacuum Transfer, Rubber + Ceramic Roller

Slotting Unit - Eight Shaft Slotting Structure, Pre-creasing, Creasing, Re-creasing, Slotting.

Die-cutter Unit - Frequency Control of Independent Motor for Line Speed Compensation

Folder Gluer & Counter Ejector - Nine Servo Motor Control with USA Valco Gluing System

For more details, please feel free to contact with us.

Thank you!!!
