3 Layer Corrugated Cardboard Production Line 7 Layer 5 Layer Carton Box Making Machine

  • 1
  • 2

Brand Name : StarPack

Model Number : ce & iso90013 5 7 layers carton box making machine

Certification : Patent Certificate, CE Certificate

Place of Origin : Foshan.CN

MOQ : 1 set

Price : Negotiation

Payment Terms : L/C, T/T

Supply Ability : 3 Sets per Month

Delivery Time : 120-160 days

Packaging Details : Steel Base with Carton Boxes and Film Wrapping

Name : Glue Kitchen

Voltage : 380V 50HZ Or Custom

Port Of Loading : Guangzhou Or Shenzhen China

Type : FULL-Automatic

Condition : Brand New

Key Words : carton box making machine

Contact Now



China factory corrugated cardboard production line with ce & iso90013 5 7 layers carton box making machine


Products Description

  1. The system paste does not need to use a stabilizer, and paste penetration is strong, and paste is stable, long-term preservation is not stratified.
  2. The entire system operation is controlled by the program Settings, and the control system software is designed and developed by the company according to the actual needs of each carton factory, stable and reliable operation.
  3. The addition of all materials through the program setting, by PLC control to complete, accurate measurement.
  4. The system is equipped with a temperature sensor and temperature display control glue temperature, to ensure that starch molecules more easily soluble in water, while avoiding the quality of glue affected by the environmental temperature and have a greater change.
  5. The equipment is equipped with an automatic tank washing program, after each transfer of glue, automatic cleaning tank.
  6. The liquid level sensor of each glue point storage tank implements the liquid level monitoring, and THE PLC automatically selects the formula to make paste according to different glue points when the liquid level is low.
  7. Shearing, mixing time through the program set by PLC control.
  8. Tablets alkalization into liquid alkali, stored in the lye storage tank; The liquid level of the lye transfer tank is controlled by PLC. When it reaches the set low limit, it will be automatically supplied by the lye storage tank through the pump.
  9. When the material level of the starch storage tank drops to the material level sensor, the system will automatically alarm prompt adding material and vibration adding material.
  10. Glue feeding through pneumatic diaphragm pump to the rubber storage tank automatically, controlled by PLC.

3 Layer Corrugated Cardboard Production Line 7 Layer 5 Layer Carton Box Making Machine
The Photo of Machine
3 Layer Corrugated Cardboard Production Line 7 Layer 5 Layer Carton Box Making Machine


Technical Parameters

Model SP-100 SP -150 SP -200 SP -220 SP -250
Layers 3/5/7 5/7
Max. Design Speed(m/min) 100 150 200 220 250
Flute Profile A,B,C,E,F,G,etc
Effective Width(mm) 1400-2000 1400-2200 1400-2500
Cutting Length(mm) 500-9999
Cutting Accuracy(mm) ±1
